Wireless Collaboration System Gateway Support Quick Sharing Multiple Screens
RHLite
RHLite Wireless Collaboration System Gateway is the most cost-effective solution for screen casting, full functions of mirroring; It is suitable fore conventional screen casting in small and medium sized meeting rooms. Factory Supply Direct!
Quantity
| Model | RHLite wireless collaboration system | ||
| Concurrent Display | 1/2 | ||
| Maximum Connections | 8 with built-in Wifi Access Point (64 with LAN) | ||
| CPU | ARM Cortex A7 Quad-Core | ||
| RAM / ROM | 1GB / 8GB | ||
| Operating System | Android 7.0 | ||
| Wifi Standards | 802. 11 b, g, n, ac | ||
| Frequencies (GHz) | 2.400 – 2.4835 | 5. 150 – 5.350 | 5.725 – 5.850 |
| Output Power (EIRP) | < 100 mW (20 dBm) | < 200 mW (23 dBm) | < 1,000 mW (30 dBm) |
| Frequency Tolerance | < 20 ppm | ||
| Spurious Emissions | < -30 dBm | ||
| LAN Port | 10/100 Ethernet RJ-45 | ||
| USB Ports | 2 x USB2.0 Type A | ||
| Display Port | 1 x HDMI | ||
| Resolutions | 1080p (1920*1200/1920x1080), WXGA (1280x800) 30fps 720p (1280x720), XGA (1024x768) 30 fps | ||
| Latency | 90- 150ms | ||
| Audio Output | 3.5mm Phone Socket | ||
| Power Supply | 12V 1A | ||
